in-building COVERAGE SOLUTIONS

Connectivity in buildings and mobile phone signaling can be compromised for many reasons, such as geographical, channel interference, or in-building structural penetration.

Poor signals can result in coverage blackspots, which lead to call dropouts, slow mobile internet, increased battery usage, or noise interference during calls.

With more than 40 years of experience and expertise, when it comes to enhancing indoor coverage RFI offers an extensive range of globally recognised DAS products and RFI-manufactured passive components to improve and strengthen indoor mobile coverage and provide a mobile booster to resolve any low signal issues.

Whatever coverage challenges your projects have, across the globe, we've got you covered.

8100 Series

The 8100 Series 5G LTE antennas not only cover the 4G LTE bands (698-960 MHz, 1710-2170 MHz, and 2300-2700 MHz) but also the new 5G LTE band (3400-3800 MHz). They are ideal for use with cellular modems & active repeaters, especially when the signal is poor.

The outstanding performance of the CDQ8100 series lies in the use of the patented Meander™ radiating elements. These Meander™ circuits are coupled together to deliver extraordinary consistency in gain, coverage pattern, and bandwidth. The result is a unique antenna able to operate across all mobile phone networks globally, housed in one unit.

Key Features:

Patented PCB-based collinear design offering the ultimate in pattern and gaining stability.
Ideal for new 5G/LTE networks with true multi-band coverage.
High gain across all bands making it suiting fringe and rural applications.
CDR & CDQ Series utilise our Q-Fit® removable whip system for ease of removal in low-height environments such as multi-story car parks, car washes, or for security.

CSM700 Series

The CSM700 is a compact low-profile omnidirectional 5G LTE antenna that provides excellent coverage for mobile and fixed data applications from 698 MHz to 3.8 GHz. The antenna features an attractive, compact housing that can be used in both indoor and outdoor applications. The CSM700 is fitted with a 13mm stud mount incorporating an integrated rubber O-ring seal and is IP65-rated.

Key Features:

Polycarbonate radome is ideal for outdoor use
Attractive, low-profile design for maximum overhead clearance
Stud mounting offers ease of installation in the field
Ingress protection to IP65

CD30 Series

RFI’s new dual band VHF/UHF antenna supports multi-band radio technology to provide interoperability among emergency management and response personnel, regardless of the frequency band used. It provides outstanding coverage of VHF and UHF band frequencies in an easy-to-install, no-tune design. Its PCB-based matching circuit is housed in a rugged, impact-resistant housing for maximum durability and its base is designed to interface with standard SO-239 (MBC) mobile base mounts to facilitate existing installation upgrades on public safety vehicles.

Key Features:

No tune, dual band coverage of VHF (148-174 MHz) and UHF (400-470 MHz) frequencies
Rugged construction for long lasting, reliable emergency response applications
MBC (SO-239) compatible interface for easy installation or upgrade
Excellent VSWR performance across frequencies

LTE-XPOL-5G Series

The LTE-XPOL-5G series consists of the very popular LTE-XPOL-002-5G 5G LTE 2x2 MIMO Directional Panel Antenna and the new 5G LTE 4x4 MIMO Directional Panel Antenna. They are excellent antenna for Fixed Wireless Access (FWA) with the 4G and 5G radio spectrum to provide wireless broadband connectivity between two fixed points, for example, a mobile network cell tower and an FWA device in a customer's home.

Key Features:

X-Polarised 2x2 or 4x4 MIMO for current and future technologies
Wideband coverage with exceptional performance
Operates from 617 to 4200 MHz
Various mounting options for ease of installation (pole or wall)
Weatherproof & waterproof (IP65)

LEGION Series

The LEGION series consists of op a range of is lightweight multi-feed screw mount antennas designed for accelerated 5GNR, WiFi-6E 2.4/5.0/6.0, and GNSS bands that operate within 617 MHz – 7125 MHz frequencies. This high-performance and high-efficiency antenna offers superior connectivity, accuracy, and reliability for ultra-wideband MIMO, wireless, and navigation, allowing devices to remain online while moving through different coverage areas. These antennas are the #1 choice for the next generation of mobile services where performance and reliability are critical such as law enforcement, medical and public transportation, automotive, and industrial automation.

Key Features:

Covers 617 MHz – 7125 MHz frequencies
5G LTE coverage with either 2x2 or 4x4 MIMO feeds
Wi-Fi coverage with either 2x2 or 4x4 MIMO feeds
GGNSS coverage including GPS/GLONASS/BeiDou/Galileo/QZS
